Thickener

product_50

LZ thickener promoted the structure of internal feed tube on the basis of traditional vertical flow sedimentation tank, which greatly increase settling efficiency. The tank is circular, suspended solids settle down into bottom conical sludge tank by gravity, clear water flow away from overflow port around the upper tank. The overflow port is equipped with scum filter and baffle to ensure the water quality.

LZ thickener promoted the structure of internal feed tube on the basis of traditional vertical flow sedimentation tank, which greatly increase settling efficiency. The tank is circular, suspended solids settle down into bottom conical sludge tank by gravity, clear water flow away from overflow port around the upper tank. The overflow port is equipped with scum filter and baffle to ensure the water quality.

Working principle

yjkuy
Deep cone thickener is a machine that based on gravity and sedimentation which makes solid-liquid separate from each other.The concentration of pulp waste water could be enhanced from 60%~ 70% to 2% ~ 15% by the machine,
the clear water is overflow from the upper part of the thickener , so as to achieve the purpose of sewage purification and solid-liquid separation.



Features

  • 1. Automatic cleaning, automatic discharge slurry, solve manual operation;
  • 2. Adopting the working principle of suspension filtration, media adsorption and settling, no purification membrane, no wearing parts;
  • 3. Made of qualified carbon steel (or stainless steel, epoxy glass fiber reinforced plastic, etc.), with good strength and corrosion resistance;
  • 4. Low flocculant using cost, big capacity, high efficiency, stable performance;
  • 5. Small volume, small floor space, easy installation;
  • 6. Service life is 10-15 years, low investment, remarkable economic benefit.
  • 7. The purified water can totally reach to national standard of discharge and can be recycled.

Specification

Model Capacity (t/h) Height (mm) Volume (m³) Weight (kg) Overall Size (mm)
S-3040 <50 4000 35 7800 3600*3600*8860
S-3060 50-100 6000 50 9000 3600*3600*10860
S-6030 100-150 3000 100 11000 6600*6600*9400
S-6040 150-200 4000 130 14000 6600*6600*10400
S-6050 200-250 5000 160 17000 6600*6600*11400
